Technische Daten
| Outer diameter lock nut (range) (d₃) (mm) | 950, 750 |
| Handle length (Lₕ) (mm) | 591 |
| Nose width (Nₖ) (mm) | 40 |
| Nose height (Nₕ) (mm) | 19 |
| Nose Length (f) (mm) | 40 |
| Thickness (n) (mm) | 40 |
| Length (L) (mm) | 715 |
| Working length (l) (mm) | 950 |
| Height (H) (mm) | 560 |
| Applicazioni consigliate | To safely tighten or loosen lock nuts after driving up large bearings on tapered seatings when working with rotating components in variety of applications with medium to large bearings and lock nuts. |
| Series | Impact spanner, TMFN |
| Tipo | Model E |
| Consente il montaggio dei cuscinetti | No |
| Compatibile con ghiere di bloccaggio in supporti ritti in due metà (SNL) di SKF | No |
| Locknut size | 800, 600 |
| Suitable SKF Locknut | HM 30/670, HM 30/710, HM 30/750, HM 30/800, HM 31/600, HM 31/630, HM 31/670, HM 31/710, HM 31/750, HME 30/670, HME 30/710, HME 30/750, HME 30/800, HME 31/600, HME 31/630, HME 31/670, HME 31/710, HME 31/750, N 670, N 710, N 750, N 800 |
| Fissaggio manico | Orientabile |
| Materiali | Testa: ghisa sferoidale, Manico: acciaio al carbonio |
| Movimentazione materiali | Manico in acciaio con impugnatura in gomma |
| Rivestimento | Testata fosfatata nera e manico zincato |
| Colore | Black metallic, silver |
| Peso netto prodotto (kg) | 10.8 |
| Codice eClass | 23-05-19-01 |
| Codice UNSPSC | 27111712 |
