NTN
Cuscinetti radiali a sfere 6072
Cuscinetto NTN 6072, Ø360×540×82 mm. Richiedi offerta — spedizione in tutto il mondo.
Tipo Cuscinetti radiali a sfere
Dimensioni
Ø 360 × 540 × 82 mm
d360Ø foro (mm)
×
D540Ø esterno (mm)
×
B82Larghezza (mm)
Richiesta offerta
Disponibile
Specifiche tecniche
| Brand | NTN |
| d - Internal diameter | 360 mm |
| D - External diameter | 540 mm |
| B - Bearing/Inner ring width | 82 mm |
| rs - Min fillet radius | 5 mm |
| Radial clearance class | CN |
| Mass | 64,7 kg |
| C - Dynamic load | 485000000 mN |
| C0 - Static load | 670000000 mN |
| Cu - Fatigue limit load | 23000000 mN |
| f0 - Coefficient | 15.7 |
| N lim - Oil lubrication limit speed | 7200 °/s |
| N lim - Grease lubrication limit speed | 6600 °/s |
| Tmin - Min operating temperature | 233,15 °K |
| Tmax - Max operating temperature | 393,15 °K |
| da min - Min shoulder diameter IR | 380 mm |
| Da max - Max shoulder diameter OR | 520 mm |
| ra max - Max shaft & housing fillet radius | 4 mm |
