NTN

Cuscinetti radiali a sfere 6216LB

Name: Cuscinetti radiali a sfere 6216LB NTN
Brand: NTN
SKU: 6216LB
Availability: InStock

Cuscinetto NTN 6216LB, Ø80×140×26 mm. Richiedi offerta — spedizione in tutto il mondo.

Codice: 6216LB

Dimensioni Ø 80 × 140 × 26 mm

d80Ø foro (mm)

D140Ø esterno (mm)

B26Larghezza (mm)

Richiesta offerta

Disponibile

Specifiche tecniche

Brand	NTN
d - Internal diameter	80 mm
D - External diameter	140 mm
B - Bearing/Inner ring width	26 mm
rs - Min fillet radius	2 mm
Radial clearance class	CN
Mass	1,4 kg
C - Dynamic load	80500000 mN
C0 - Static load	53000000 mN
Cu - Fatigue limit load	3950000 mN
f0 - Coefficient	14.6
N lim - Oil lubrication limit speed	31800 °/s
N lim - Grease lubrication limit speed	27000 °/s
Tmin - Min operating temperature	248,15 °K
Tmax - Max operating temperature	383,15 °K
da min - Min shoulder diameter IR	89 mm
da max - Max shoulder diameter IR	95,5 mm
Da max - Max shoulder diameter OR	131 mm
ra max - Max shaft & housing fillet radius	2 mm
